MATCH ROUTE AVAILABLE
GLOBAL ANSI PUMP REPLACEMENT SOLUTIONS100% INTERCHANGEABLE REPLACEMENT
100% Interchangeable PumpWorks PWA Gen2 Replacement Pump
A G196 replacement route for corresponding PumpWorks PWA Gen2 ANSI/ASME B73.1 group and pump-size configurations. Select the existing PWA group, then verify size, hydraulic duty, material and installation interfaces.
- ANSI / ASME B73.1
- Frame / Group Matched
- Dimensional Fit Review
- Engineering Verified
For corresponding ANSI/ASME B73.1 pump size and frame configurations. Final hydraulic duty, material, seal arrangement and site-specific interfaces are verified before quotation.
- 01
EXISTING PUMPPumpWorks PWA Gen2
- 02
MATCHGroup + Pump Size
- 03
VERIFYDimensional Route + Hydraulic Review
- 04
SUPPLYComplete G196 / Parts
EXISTING PUMP MODEL FINDER
What PWA Gen2 Group Do You Have?
Select the identification shown on the existing pump, then enter the exact pump size. Unverified configurations do not produce a fabricated match.
| OEM frame / group | OEM size | G196 frame | G196 size | Status |
|---|---|---|---|---|
| Group 1 | Enter nameplate size | Defined after size review | Confirmed after size review | MATCH ROUTE AVAILABLE |
| Group 2 | Enter nameplate size | Defined after size review | Confirmed after size review | MATCH ROUTE AVAILABLE |
| Group 3 | Enter nameplate size | Defined after size review | Confirmed after size review | MATCH ROUTE AVAILABLE |
| Group 4 | Enter nameplate size | Engineering confirmation | Engineering confirmation | ENGINEERING REVIEW REQUIRED |
Group 2
- OEM size
- Enter nameplate size
- G196 frame
- Defined after size review
- G196 size
- Confirmed after size review
MATCH ROUTE AVAILABLE
Group 3
- OEM size
- Enter nameplate size
- G196 frame
- Defined after size review
- G196 size
- Confirmed after size review
MATCH ROUTE AVAILABLE
Group 4
- OEM size
- Enter nameplate size
- G196 frame
- Engineering confirmation
- G196 size
- Engineering confirmation
ENGINEERING REVIEW REQUIRED
Engineering boundary
PWA Group → Size → Dimensional Route → Hydraulic Review → RFQ. Group 4 remains under engineering review until an approved cross-reference confirms the exact configuration.
ENGINEERING PROOF
What We Verify for Dimensional Interchangeability
Final fit is confirmed against the selected pump size, approved drawing and available installation data before order.
Suction flange / centerlineSize, location and piping relationship
Discharge flange / centerlineOrientation, height and connection
Shaft centerlineDriver and coupling alignment
Pump feetMounting and baseplate relationship
Shaft / coupling interfaceDrive interface and guard clearance
Baseplate relationshipConfirmed for the selected configuration
Dimensional Match
- ANSI size
- Frame / group
- Nozzle relationship
- Mounting interface
- Drive interface
Hydraulic Match
- Flow
- Head
- Speed
- Impeller
- Curve review
Construction Match
- Wet-end material
- Shaft / sleeve
- Seal chamber
- Mechanical seal
- Power end
HYDRAULIC DUTY VERIFICATION
Confirm Your Duty Point
Dimensional interchangeability and hydraulic selection are verified separately. Enter the available duty data for engineering curve review.
MATERIALS & CONSTRUCTION
Select Required Material
Company-level material capability is shown here. Final availability and exact grade for the selected pump size and service are confirmed during engineering review.
G196 SERIES REFERENCE ENVELOPE
Series limits, not every-size promises
Series maximum values are reference envelopes. Final performance is confirmed on the reviewed curve for the selected pump size, speed and impeller diameter.
- capacity
- Up to 7,000 US GPM / 1,590 m³/h
- head
- Up to 730 ft / 223 m
- pressure
- Up to 375 psig / 2,586 kPa
- temperature
- Up to 700°F / 371°C
- frames
- STX / MTX / LTX / XLTX
- standard
- ASME/ANSI B73.1
- impeller
- Open impeller / external adjustment
PRIMARY SUPPLY
Complete G196 Replacement Pump for PWA Gen2
The reviewed model, duty, material, seal and installation interface package defines the quotation scope.
- Complete pump assembly
- Reviewed wet-end construction
- Seal arrangement
- Curve and technical documentation
- Motor and coupling review
- Approved drawing confirmation
HOW WE VERIFY YOUR REPLACEMENT
From Existing Pump to Reviewed Quotation
- 01Identify
Nameplate, model, size, frame/group and drawing.
- 02Confirm
Dimensions, duty, material, seal and site interfaces.
- 03Define Scope
Complete pump or reviewed replacement parts.
- 04Receive Proposal
Confirmed model, technical scope and quotation.
TECHNICAL FAQ
PumpWorks PWA Gen2 Replacement Questions
Which G196 route corresponds to PWA Gen2 Group 1, 2 or 3?
Groups 1, 2 and 3 enter the published replacement route. The final G196 frame and size are assigned only after the existing group and pump size are checked.
Does PWA Gen2 Group 4 require engineering review?
Yes. Group 4 is marked Engineering Review Required until approved size and dimensional data support the exact configuration.
Can I replace a PWA Gen2 without changing the ANSI installation?
Corresponding ANSI interfaces are reviewed for dimensional fit. The selected size, drawing and site interfaces determine whether any installation adjustment is required.
What information should I upload for PWA replacement verification?
Upload the nameplate and GA drawing, then provide group, size, duty point, liquid, temperature, material and seal arrangement.
Are complete pumps and parts available?
Complete G196 replacement pumps are the primary scope. Reviewed replacement parts can also be quoted from the PWA reference or part number.
