Interchangeable ANSI Pump Parts — Goulds 3196 & Durco Mark III
100% dimensionally interchangeable with OEM parts — no modifications required. Complete wet-end and power-end component coverage for Goulds 3196 and Durco Mark III
48-hour emergency dispatch for critical MRO parts from rotating stock. 30-50% cost savings vs OEM with identical material specifications and performance
OEM part number cross-reference service: submit your OEM part number and receive the equivalent within 24 hours. Full material traceability and inspection reports included
Product Details
| Application | MRO replacement parts, equipment maintenance, pump repair and overhaul, emergency breakdown replacement, planned maintenance programs, spare parts inventory management |
| Flow Rate | N/A (Replacement Parts) |
| Head Range | N/A (Replacement Parts) |
| Temperature | N/A (Replacement Parts) |
| Materials | CF8M (316SS), CD4MCuN (Duplex), CN7M (Alloy 20), WCB, Hastelloy B, Hastelloy C-276, Nickel 200, Titanium, Zirconium 702 — all castings with material certification and traceability |
| Pressure Rating | N/A (Replacement Parts) |
Interchangeable ANSI Pump Parts — Keep Your Pumps Running
We review complete pumps, matched wet-end assemblies and supported individual casing, cover, impeller, shaft and selected metallic seal components for Goulds 3196 and Durco Mark III ANSI B73.1 process pumps. Every part is dimensionally verified against OEM drawings and manufactured to the same material specifications — at 30–50% lower cost than OEM spare parts.
Supported Replacement Components (Engineering Review)
| Part | Reference Scope | Verification |
|---|---|---|
| Casing | Gxx100 / Dxx100 | Drawing, model and material review |
| Impeller | Gxx3 / Dxx3 | Hydraulic and dimensional review |
| Cover | Gxx106 / Dxx106 | Matched wet-end review |
| Shaft | Gxx105 / Dxx105 | Fit, material and configuration review |
| Selected metallic seal components | Drawing-based | Engineering review required |
Why Choose a Verified Replacement Review
- Scope confirmed before production — Fit, material and documentation are confirmed for supported casing, cover, impeller, shaft and selected metallic seal components.
- Full MTR Package — EN 10204 3.1 certificates included with every shipment. PMI verification available on request.
- Reverse Engineering — If you have an obsolete or discontinued part, send us the drawing or sample. We reverse-engineer and manufacture in 4–8 weeks.
- Any Material — CF8M (316SS), CD4MCuN (Duplex), CN7M (Alloy 20), Hastelloy B & C-276, Titanium Gr.2 & Pd7B, Zirconium 702.
How to order: Send us the OEM part number (or Yingsiman P/N from our Cross-Reference Guide), quantity, and material preference. We quote within 24 hours.
