A bearing-life plan works best when it follows the installed pump configuration, the current Flowserve instructions and the site’s operating history. Durco Mark 3 ANSI pumps are available in different sizes, Groups and lubrication arrangements, so this guide avoids universal oil grades, clearances and inspection intervals.
Use this page to organize routine care before a failure occurs. If a bearing has already failed, preserve the as-found evidence and follow the Durco Mark III bearing-failure diagnosis guide.
Identify the Installed Mark 3 Configuration
Record the pump nameplate details and the installed power-end arrangement before selecting service parts or maintenance instructions. Capture the model, size, Group or configuration, serial or order information where available, driver, lubrication method and the revision of the drawings and user instructions used at the site.
Use the current Flowserve Durco Mark 3 ASME (ANSI) product information and the instructions applicable to the installed unit. A family name alone is not enough to establish a bearing arrangement, lubricant quantity, fit or impeller-setting value.
Keep Lubrication Within the OEM Specification
Confirm whether the installed bearing housing uses oil bath, oil mist, grease or another specified arrangement. Apply only the lubricant type, viscosity, level and service method stated for that configuration. Do not transfer values from a different Group or infer a fill quantity from a photograph or a general pump-family reference.
During scheduled rounds, record lubricant condition and any relevant housing temperature or leakage observation. Check the breather, sight glass, seals, isolators and housing joints where fitted. Investigate water, particles, foaming, discoloration or an unexplained change in lubricant consumption. Oil analysis may be useful for critical assets when the sample method and interpretation follow the site’s reliability program.
Set inspection and change intervals from the applicable OEM guidance, the lubricant supplier’s requirements and site experience. Shorten the review cycle when the service is unusually hot, contaminated, frequently started or otherwise severe; document the reason for any site-specific interval.
Trend Condition Against a Known Baseline
Build a baseline while the pump is operating in a stable, documented condition. Record the measurement location and method together with vibration, bearing-housing temperature, noise, leakage and relevant process readings. Where available, include flow, discharge pressure, speed, liquid properties and suction conditions.
Trend comparable readings over time and investigate a sustained change or a cluster of symptoms. Vibration and temperature limits vary by configuration, sensor location, operating state and site criteria; use the applicable OEM instructions and approved site alarm limits rather than a universal number.
Protect Alignment and Bearing Fits During Maintenance
After work on the driver, coupling, baseplate, piping or power end, verify the alignment using the site’s approved procedure and account for the specified cold or hot condition. Check soft foot, hold-downs and base condition where relevant. Confirm that connected piping is supported and does not force the casing out of position.
During an overhaul, record the as-found condition before cleaning. Measure shaft runout, bearing-seat condition, endplay and housing fits only at the locations and against the limits specified for the installed Group and drawing revision. Protect machined surfaces during handling and keep parts identified until the inspection is complete.
If impeller adjustment is required, use the procedure for the exact Mark 3 arrangement. The Goulds 3196 and Durco Mark III adjustment comparison explains why a procedure from another pump family should not be substituted.
Keep the Pump Within Its Verified Duty
Review the actual operating point against the approved performance curve and the operating limits for the installed configuration. Record meaningful changes in speed, flow, liquid properties, suction pressure, valve position or process demand. Persistent operation away from the intended duty can contribute to unstable hydraulic forces and should prompt an engineering review.
For a duty change, confirm the available suction conditions and compare the field readings with the verified curve. Use the site’s approved process for deciding whether controls, system conditions or the pump selection need review; do not treat a single vibration or temperature reading as proof of a hydraulic cause. See the pump performance-curve resource for the data needed to evaluate duty.
Keep a Practical Bearing-Maintenance Record
Maintain one record for the pump configuration and each significant inspection or service event. A useful record includes:
- Nameplate, Group, configuration, serial or order reference and drawing revision.
- Lubrication arrangement, specified lubricant, service date and observed condition.
- Comparable vibration, temperature, noise and leakage observations with the measurement method.
- Operating condition at the time of measurements, including flow, speed and relevant suction data where available.
- Alignment, piping, coupling or power-end work completed since the previous reading.
- As-found measurements, replaced parts, inspection photographs and the applicable acceptance references.
Choose review frequency from the OEM instructions, operating hours, process severity, contamination exposure, starts and stops, historical trends and the site’s criticality program. Record the chosen frequency and revise it when operating evidence changes.
Durco Mark III Bearing-Maintenance FAQs
How often should I inspect Durco Mark III bearings?
There is no single interval that fits every installation. Follow the applicable Flowserve instructions and set site rounds and service timing from duty severity, operating hours, contamination exposure, asset criticality and condition trends.
Can every Mark 3 use the same oil grade or fill quantity?
No. Confirm the lubrication arrangement and values for the installed Group and bearing housing using the matching instructions. Do not copy a value from another configuration.
Which readings should I trend?
Use repeatable vibration and bearing-housing temperature measurements, together with noise, leakage, lubricant condition and the relevant operating state. Compare like-for-like readings with the asset baseline and approved limits.
What should I do if readings change or a bearing fails?
Document the operating state and maintenance history, then investigate the change using the applicable inspection requirements. If a bearing has failed, preserve the as-found condition and use the failure-diagnosis guide to organize the next checks.
Durco Mark III Bearing Maintenance Log
Keep measurements comparable: use the same location, method and operating condition where practicable, and identify any change. Establish alarm and action limits from the applicable OEM instructions and site reliability program. A generic calendar interval or a single temperature reading cannot establish remaining bearing life.
| Record group | Fields to keep | Review trigger |
|---|---|---|
| Asset and lubrication basis | Pump tag, Group, size, power-end arrangement, lubrication method, lubricant specification, IOM revision and approved interval. | A different lubricant, housing or configuration is installed. |
| Condition round | Date, operator, speed, flow/load, measurement location, vibration result/units, housing temperature, noise/leakage and lubricant condition. | A repeatable trend changes or an approved site limit is exceeded. |
| Maintenance event | As-found condition, alignment/fit inspection, work performed, lubricant quantity per applicable instructions and replaced part references. | After overhaul, seal work, alignment changes or extended storage. |
| Return to service | Applicable procedure, post-work baseline, operating state, remaining observations, action owner and next review. | New baseline differs from the accepted operating record. |
If the record points to a failed bearing, retain the as-found evidence and use the bearing-failure diagnosis guide. For replacement enquiries, the Group 2 identification guide helps distinguish supported wet-end components from power-end technical references. Bearing numbers or housing references on a diagram do not establish standalone supply.
Open the copyable review worksheet
Edit the known fields, leave missing information marked as pending, and copy the text into your maintenance record or enquiry. This worksheet does not submit data.
